16 Operating instruction SCK Gas Sampling System OI/SCK-EN Rev. E
Technical data
The following sound emission may be expected when operating the retractor
and cooling module:
Cooling module sound emission
The following table lists the dimensions and weights of the main modules of
the gas sampling system:
Retractor:
Width 800 mm, Height 600 mm, Length 4500 / 5500
mm
Probe H:
95 kg (for 3 m special length)
Probe 60S:
45 kg (for 3 m special length)
Control cabinet:
Width 800 mm, Height 1000 mm, Depth 300 mm
Cooling module:
Width 1200 mm, Height 1500 mm, Depth 800 mm
Transformer (optional):
Width 634 mm, Height 953 mm (with base and
transport lugs), Depth 400 mm
250-l compressed-air tank (optional):
Height 1785 mm, Diameter 530 mm
Sound emission
Dimensions and
weights
