86 Operating instruction SCK Gas Sampling System OI/SCK-EN Rev. E
General transport information
Danger of crushing when lifting or lowering the transport unit
 Only appropriately trained personnel may transport the transport units and
only with the aid of the recommended transport equipment.
 Do not stand under suspended loads.
 Follow the transport instructions in these operating instructions care-
fully.
Risk of injury in the area of the gas sampling system due to moving or fall-
ing parts, anti-freeze, lubricating oil
Wear general personal protective equipment:
 Closed overalls with long trousers and long sleeves
 Safety shoes
 Safety gloves suitable for mechanical work
 Safety glasses
 Protective helmet
 If necessary, additional protective equipment if prescribed by the opera-
tor.
During transport make sure that the transport packaging is not damaged or
removed. Observe the below-mentioned temperature and humidity limits
during transport.
In the event of transport damage attributable to improper handling, instigate
damage assessment by the carrier (rail, post office, and forwarder) within
seven days.
Make sure that none of the enclosed accessories are lost during unpacking.
Store the screws in case the unit needs to be transported again in the future.
The retractor including the probe weighs 450–500 kg depending on the
length of the retractor and type of probe. A crane and suitable transport
equipment is required for transport and unpacking. Use the transport lugs to
fasten the lifting ropes. The lifting ropes must be long enough to ensure an
angle of at least 60° under strain. Otherwise the retractor cabinet can get
twisted.
If the cooling module is also transported by crane, observe the same points.
Heavy transport
units
Mechanical and
material dangers
General remarks
regarding transport
Transport with crane
