ABB SCK - Installing the Compressed-Air Supply

OI/SCK
-EN Rev. E Operating instruction SCK Gas Sampling System 101
Installing the compressed-air supply
Risk of injury in the area of the gas sampling system due to moving or fall-
ing parts, hot surfaces, anti-freeze, compressed air, lubricating oil
Wear general personal protective equipment:
 Closed overalls with long trousers and long sleeves
 Safety shoes
 Safety gloves suitable for mechanical work
 Safety glasses
 Protective helmet
 If necessary, additional protective equipment if prescribed by the opera-
tor.
The location of the pneumatic connections on the probe retractor can be
found in the pneumatic/hydraulic interface plan in the appendix. All required
lines are pre-installed in the probe retractor area. All downline connections as
connected from the central connection point on top of the probe retractor.
 Pneumatic/hydraulic interface plan
The following assembly screws are required for installation of the com-
pressed-air tank:
 3 galvanized steel screws (or stainless material) or bolts M12
The following conditions must be met:
 Compressed air conforms to the required quality of compressed air; see
Power and compressed-air supply conditions .
 When setting up the compressed-air tank: The site conforms to the desig-
nated site conditions (criteria see Choosing the place of installation of the
peripheral modules ).
Proceed as follows to install the compressed-air tank:
Step Procedure
1
Fasten compressed-air tank in suitable position (see Choosing
the place of installation of the compressed-air tank ) with 3
galvanized steel screws (or stainless material) or bolts M12 on
the ground.
2
Pneumatically connect compressed-air tank as per pneumatic/-
hydraulic interface plan (see appendix) to the gas sampling
system.
Mechanical, thermal
and material dangers
Position of the
connections
Required documents
Assembly screws for
compressed-air tank
Requirements
Connecting the
compressed-air tank
(optional)
