ABB SCK - Installing the Probe Retractor

OI/SCK
-EN Rev. E Operating instruction SCK Gas Sampling System 97
Installing the probe retractor
Risk of injury in the area of the gas sampling system due to moving or fall-
ing parts, hot surfaces, anti-freeze, compressed air, lubricating oil
Wear general personal protective equipment:
 Closed overalls with long trousers and long sleeves
 Safety shoes
 Safety gloves suitable for mechanical work
 Safety glasses
 Protective helmet
 If necessary, additional protective equipment if prescribed by the opera-
tor.
Danger of crushing when lifting or lowering the transport unit
 Only appropriately trained personnel may transport the transport units and
only with the aid of the recommended transport equipment.
 Do not stand under suspended loads.
 Follow the transport instructions in these operating instructions care-
fully.
Risk of burning due to jet flames and hot gases at the uncovered duct open-
ing when the rotary kiln is in operation.
 Preferably install or remove the probe when the rotary kiln is out of opera-
tion.
 If you install or remove the probe when the rotary kiln is in operation:
 Wear a face mask against heat, heat-proof gloves and protective weld-
er's clothing and respiratory protection against toxic gases.
 Keep the time in which the duct opening is open as short as possible.
 6 suspension bolts, diameter 16 mm, material round steel S235JR (St37)
The following requirements must be met in order to install the probe retrac-
tor:
 The site conforms to the designated site conditions (criteria see Choosing
the place of installation of the peripheral modules ).
 6 fastening points are present to affix the probe retractor.
 The probe retractor is unpacked.
How to install the probe retractor:
Step
Procedure
1
Set up probe retractor at the place of installation.
Mechanical, thermal
and material dangers
Heavy transport
units
Hot surfaces, hot
gases, jet flames
Screws required for
assembly
Requirements
Instructions:
Installing the probe
retractor
