94 Operating instruction SCK Gas Sampling System OI/SCK-EN Rev. E
Overview: installation
This section contains a list of tasks to be performed when installing the gas
sampling system. Links are given to the specific installation instructions
describing installation of the various modules in detail.
It is recommended to have initial startup of the gas sampling system per-
formed by the manufacturer's trained personnel or by the supplier.
In order to be able to install the various modules of the gas sampling system,
preparations must be made at the cement works. A list of preparatory tasks is
given in the "Engineering Guideline".
The rotary kiln must be shut down during installation of the wall tube. Instal-
lation of the gas sampling system should also preferably be performed while
the kiln is shut down. If installation is performed while the kiln is operating,
personnel must always wear adequate heat-proof clothing during assembly of
the probe retractor (uncovered duct opening!).
Proceed as follows to install the complete system:
Check place of installation
of the various modules of
Checking site conditions
on
page 95
Install the probe retractor
such that personnel are
not endangered and the
system cannot be dam-
Installing the probe retractor
on page 97
Install control cabinet in
suitable place.
Installing the control cabinet
on page 100
supply, install com-
pressed-air tank if neces-
Installing the compressed-
air supply
on page 101
Installing the cooling module
on page 103
Lay and connect cooling
water hoses.
Installing the cooling water
circuit
on page 104
gas line to retractor.
Connecting the sample gas
line to the retractor
on page
Connecting internal electric
cables
on page 106
Connect external electric
cables.
Connecting external electric
cables
on page 108
Introduction
installations
and installation
