ABB SCK - Optimizing Operating Parameters

OI/SCK
-EN Rev. E Operating instruction SCK Gas Sampling System 51
Optimizing operating parameters
The control system has factory settings that need to be modified to specific
system conditions at start-up. You can edit alarm limits in a set range to suit
specific system conditions. Limited configuration serves to protect the probe
retractor against harmful or contradictory settings. A list of operating pa-
rameters with defaults can be found in Default operating parameter settings
on page 48.
A password for a certain access level is required to edit parameters:
Level 1
Level 2
Level 3
Edit time values
X
X
Edit limits
X
X
Edit basic values
X
X
Proceed as follows to edit a time parameter:
Step
Procedure
1
Open the Time Values parameter screen.
Path: Setup ► Time Parameters
2
Select parameter and enter appropriate value in the input box.
Note: You can only edit time values within the tolerance limits.
3
Click the Save button to save the settings.
Proceed as follows to edit a limit parameter:
Step Procedure
1
Open the Alarm Values parameter screen.
Path: Setup ► Limit Parameters
2
Select parameter and enter appropriate value in the input box.
Note: You can only edit limits within the tolerance limits.
3
Click the Save button to save the settings.
Proceed as follows to edit a basic parameter:
Step
Procedure
1
Open the Basic Values parameter screen.
Path: Setup ► Basic Parameters
2
Select parameter and enter appropriate value in the input box.
Note: You can only edit basic values within the tolerance limits.
3
Click the Save button to save the settings.
Introduction
Access levels
Edit time values
Edit limit values
Edit basic values
