124 Operating instruction SCK Gas Sampling System OI/SCK-EN Rev. E
Starting frequency converter and adapting control parameters
Risk of injury in the area of the gas sampling system due to moving or fall-
ing parts, hot surfaces, hot cooling water, anti-freeze, compressed air,
lubricating oil
Wear general personal protective equipment:
Closed overalls with long trousers and long sleeves
Safety shoes
Safety gloves suitable for mechanical work
Safety glasses
Protective helmet
If necessary, additional protective equipment if prescribed by the opera-
tor.
Danger of electric shock when control cabinet is open, open connection or
terminal boxes
Only specialized electrical personnel may work on the electrical system.
Observe national regulations pertaining to electrical equipment.
The main terminals -X30, -X40 and the input terminals of the main
switches -Q30, -Q40 are live even when the main switches are off.
All metallic parts in the environment that can be touched at the same
time as the machine must also be grounded together.
Check pre-protection according to the documentation.
The frequency converter ACS355 controls the heat exchanger motor. In order
to ensure constant cooling-water temperature, the factory-set default control
parameters must be adapted to the conditions at the installation site.
Refer to the ACS355 manual for further information on operating the frequen-
cy converter.
Control cabinet key to open the control cabinet
The following conditions must be met:
The service switch is in the
ON
position; the gas sampling probe is retracted
from the kiln (see
Operating the service switch
on page 161).
Mechanical, thermal
and material dangers
components
