ABB SCK - Checking Site Conditions

OI/SCK
-EN Rev. E Operating instruction SCK Gas Sampling System 95
Checking site conditions
Risk of injury in the area of the gas sampling system due to moving or fall-
ing parts, hot surfaces, anti-freeze, compressed air, lubricating oil
Wear general personal protective equipment:
 Closed overalls with long trousers and long sleeves
 Safety shoes
 Safety gloves suitable for mechanical work
 Safety glasses
 Protective helmet
 If necessary, additional protective equipment if prescribed by the opera-
tor.
The purpose of this task is to check whether the gas sampling system site is
correctly prepared.
How to check site conditions:
Step
Procedure
1
Using the checklist, check whether the site conditions for the
various modules of the gas sampling system are fulfilled and
that preparations for installation have been completed.
2
Only continue with installation of the gas sampling system
once all conditions have been met.
The following conditions must be met:
Conditions
Description in the
"Engineering Guideline" in ...
OK
General rules regarding choice
of installation site were ob-
served, environmental condi-
tions taken into account.
General rules regarding choosing
the place of installation of the
peripheral modules
Environmental condition re-
quirements
Installation position of probe
and probe retractor defined.
Positioning the gas sampling
probe
There is a suitable position to
install the control cabinet with
an unobstructed view of the
probe retractor.
Choosing the place of installation
of the control cabinet
Position to set up the cooling
module defined.
Choosing the place of installation
of the cooling module
If a compressed-air tank is
required: Position to set up the
compressed-air tank defined.
Choosing the place of installation
of the compressed-air tank
Mechanical, thermal
and material dangers
Meaning
Instructions
Site conditions
checklist
