Preparing the compressed-air supply
Risk of injury in the area of the gas sampling system due to moving or fall-
ing parts, hot surfaces, hot cooling water, anti-freeze, compressed air,
lubricating oil
Wear general personal protective equipment:
 Closed overalls with long trousers and long sleeves
 Safety shoes
 Safety gloves suitable for mechanical work
 Safety glasses
 Protective helmet
 If necessary, additional protective equipment if prescribed by the opera-
tor.
Danger due to skin and eye injuries in the event of contact with lubricating
oil from the pneumatic box of, from the filter muffler or from inside the
pneumatic motor.
 Avoid contact with lubricating oil.
 Wash any lubricating oil off the skin immediately with water and soap.
 If any lubricating oil gets in the eyes despite protective glasses, rinse
them thoroughly under running water, holding the eyelids open.
 Observe instructions in the lubricating oil manufacturer's safety data
sheet.
Lubricating oil "D" DIN 51502, kinematic viscosity 30 mm
2
/s(cST) at 40 °C (ISO
VG 32, DIN 51519)
The compressed air must meet the following minimum requirements:
Dew point +3 °C
Pressure 6 bar (6000 hPa) positive pressure
Consumption approx. 3 m
3
/h
One probe travel (2 x 20 s) requires approx. 1 m
3
.
Other requirements are:
 The compressed air must be free of dirt and oil/water droplets.
 At ambient temperatures below 0 °C make sure that the compressed-air
supply cannot freeze.
Mechanical, thermal
and material dangers
Harmful
lubricating oil
Lubricating oil
requirements
Compressed-air
requirements
