96 Operating instruction SCK Gas Sampling System OI/SCK-EN Rev. E
Conditions Description in the
"Engineering Guideline" in ...
OK
A suspension device for the
probe retractor has been pre-
pared and holes drilled for
installation of the other mod-
ules.
Fastening elements and attach-
ment points
Wall tube and mounting flange
manufactured and installed.
Creating the wall tube with
mounting flange
Installing the wall tube
The power and compressed-air
supply conforms to the re-
quirements of the gas sam-
pling system.
Power and compressed-air supply
requirements
Air cannon, if present, is inte-
grated into the gas sampling
system control system only.
Integrating the air cannon into
the control system
The danger area around the
probe retractor is protected by
a protective installation.
Creating the base area for the
retractor
Creating the protective installa-
tion around the retractor
