OI/SCK
-EN Rev. E Operating instruction SCK Gas Sampling System 179
Proceed as follows:
Step
Procedure
1
Allow gas sampling probe to cool down.
WARNING! Risk of burning in the event of contact with the hot
probe. Do not touch the probe until it has cooled down to
below 50 °C.
2
Unscrew the adjustment screws (1) on the probe carriage until
you can swing the probe out.
3
Swing the probe out to the right.
Swinging the probe
tip out
