-EN Rev. E Operating instruction SCK Gas Sampling System 25
No.
Component
Function
11
Probe cleaning unit
Controls cleaning functions on
the sample gas probe.
The probe is automatically retracted if the following malfunctions occur:
 Cooling water temperature too high
 Cooling water flow rate too low
 Cooling water pressure too low
 Circulation pump failure
 Power supply interrupted
 Compressed air failure
To protect the process against ambient air from being drawn in and to pro-
tect operators, the duct opening is closed by a shutter when the probe is
retracted. This does not apply, however, to regular retraction/extension for
cleaning the outside of the probe.
The shutter is moved either automatically by a pneumatic drive or manually.
The pneumatic/electric supply is connected at a central transition point. All
required line connections are pre-installed in the probe retractor.
Retraction in the
event of malfunction
Shutter
Supply lines
