-EN Rev. E Operating instruction SCK Gas Sampling System 49
The control system has the following factory settings that need to be modi-
fied to specific system conditions at start-up:
Parameter
Default
Tolerance range
C. Water Flow Temp. MIN
10 °C
5–25 °C
C. Water Flow Temp. MAX
80 °C
40–90 °C
C. Water Return Temp. MAX
85 °C
40–135 °C
C. Water Return Temp. MAX2
95 °C
90–100 °C
C. Water Flow Rate MIN
12 l/min
5–45 l/min
C. Water Flow Rate MIN2
11 l/min
1–35 l/min
C. Water Pressure MIN
350 mbar
300–900 mbar
C. Water Pressure MIN2
150 mbar
50–600 mbar
C. Water Pressure MAX
2500 mbar
2250–2750 mbar
C. Water Flow / Return Temp. Diff.
2 °C
1–15 °C
Probe Heating Temp. MIN
5 °C
1–100 °C
Probe Heating Temp. MAX
190 °C
30–200°C
Sample Gas Probe Pressure
(indicated only when SCK is connected
to the ACX analysis system)
600 mbar
250–900 mbar
Limit parameters
