90 Operating instruction SCK Gas Sampling System OI/SCK-EN Rev. E
Module
Weight
Transport conditions
Control cabi-
net
75 kg

Mark connecting cables so that you know where to install what.
 Lay the control cabinet on its back for transport.
 Use a suitable transport pallet for transport.

Transport recommendation: For
-lift truck or hand lift
Compressed-
air tank
90 kg
 Disassemble the compressed-air system for transport.
 The compressed-air tank may only be transported on its side.
 Ensure adequate protection of the attachments.

Transport recommendation: For-lift truck or hand lift
Transformer
140 kg

Use a suitable transport pallet for transport.
 Lifting gear may only be attached at the designated attachment
points (transport lugs).

Transport recommendation: For-lift truck, hand lift or crane
