112 SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B
… 9 Operation
… Parameter descriptions
Display / ...Operator Pages /
...Operator Page 1 (n)
Display Mode
Configure each operator page.
The following versions can be selected:
Off,
Graph View, 1x4, 1x6A, 1x6A bar, 1x9, 1x9 bar, 2x9, 2x9 bar, 3x9.
Selecting ‘Off’ deactivates the corresponding operator page.
1st Line
Selection of process variable displayed in the respective row.
See table
Available process variables on page 98.
2nd Line
3rd Line
4th Line
Bargraph
Select the process variable
displayed as a bar graph (only in display modules with “Bar” bar graph).
•
Mass Flow [%]: Mass flow in %
•
Volume Flow [%]: Volume flow in %
Graph View
Select the process variable displayed as a graphic view (available only for user page 1).
