ABB SensyMaster FMT430 - Cfmus

SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B 9
cFMus
Note
• A specific marking applies, depending on the design.
• ABB reserves the right to modify the Ex-marking. Refer to the name plate for the exact marking.
Model number design*: FMTabcdefghijkl.m.n.o.p
* For detailed information on the design of the model number, see the ordering information in the data sheet
Model number for use in Division 2
Ex marking
FMT4x0
- F2 (i=D..,Y..,S..)
Sensor in integral mount design with single
-
compartment or dual
-compartment housing.
Design in accordance with
ANSI / ISA 12.27.01 as ‘
Dual
Seal Device
’.
USA:
Certificate:
FM19US0110X
NI: CL I, Div 2, GPS ABCD T6...T1
DIP: CL II,III, Div 2, GPS EFG T6...T
3B
CL I, ZN 2, AEx ec IIC T6...T1 Gc
ZN 21, AEx tb IIIC T80°C...T165°C Db
See handbook for temperature class information
Canada:
Certificate:
FM19CA0055X
NI: CL I, Div 2, GPS ABCD T6...T1
DIP: CL II,III, Div 2, GPS EFG T6...T3B
CL I, ZN 2, Ex ec IIC
T6...T1 Gc
Ex tb IIIC T80°C...T165°C Db
ANSI/ISA 12.27.01: Dual Seal
FMT4x2
- F2 (i=W..,R..)
Transmitter in remote mount design with single
-
compartment or dual
-compartment housing.
USA:
Certificate:
FM19US0110X
NI: CL I, Div 2, GPS ABCD T6
DIP: CL II,III,
Div 2, GPS EFG T6
CL I, ZN 2, AEx ec IIC T6 Gc
ZN 21, AEx tb IIIC T80°C Db
See handbook for temperature class information
Canada:
Certificate:
FM19CA0055X
NI: CL I, Div 2, GPS ABCD T6
DIP: CL II,III, Div 2, GPS EFG T6
CL I, ZN 2, Ex ec IIC T6 Gc
Ex tb
IIIC T80°C Db
Model number for use in Division 1
Ex marking
FMT4x0
– F1 (i=D1...D8)
Sensor in integral mount design or remote mount
design with dual
-compartment housing.
Design in accordance with
ANSI / ISA 12.27.01 as ‘
Dual
Seal Device
’.
USA:
Certificate:
FM19US0110X
S
-XP-IS: CL I, Div 1, GPS ABCD T6...T1
DIP: CL II,III, Div 1, GPS EFG T6...T3B
CL I, ZN 1, AEx db eb ia mb IIB+H2 T6...T1 Gb
ZN 21, AEx ia tb IIIC T80°C...T165°C Db
See handbook for temperature class information and
installation drawing 3kxf000094G0009
Canada:
Certificate:
FM19CA0055X
S
-XP-IS: CL I, Div 1, GPS BCD T6...T1
DIP: CL II,III, Div 1, GPS EFG T6...T3B
CL I, ZN 1, AEx db eb ia mb IIB+H2 T6...T1 Gb
Ex ia tb IIIC T80°C...T165°C Db
IN
-/OUTPUTS: Urated=30V
ANSI/ISA 12.27.01: Dual Seal
FMT4x0
– F1 (i=Y0)
Sensor in remote mount design.
Design in accordance with
ANSI / ISA 12.27.01 as ‘
Dual
Seal Device
’.
USA:
Certificate:
FM19US0110X
S
-XP: CL I, Div 1, GPS ABCD T6...T1
DIP: CL II,III, Div 1, GPS EFG
T6...T3B
CL I, ZN 1, AEx db eb mb IIB+H2 T6...T1 Gb
ZN 21, AEx tb IIIC T80°C...T165°C Db
See handbook for temperature class information and
installation drawing 3kxf000094G0009
Canada:
Certificate:
FM19CA0055X
S
-XP: CL I, Div 1, GPS BCD T6...T1
DIP: CL
II,III, Div 1, GPS EFG T6...T3B
CL I, ZN 1, Ex db eb mb IIB+H2 T6...T1 Gb
Ex tb IIIC T80°C...T165°C Db
ANSI/ISA 12.27.01: Dual Seal
FMT4x2
– F1 (i=R1...R8)
Transmitter in remote mount design with dual
-
compartment housing
USA:
Certificate:
FM19US0110X
XP
-IS: CL I, Div 1, GPS BCD T6
DIP: CL II,III, Div 1, GPS EFG T6
CL I, ZN 1, AEx db ia IIB+H2 T6 Gb
ZN 21, AEx ia tb IIIC T80°C Db
See handbook for temperature class information and
installation drawing 3kxf000094G0009
Canada:
Certificate:
FM19CA0055X
XP
-IS: CL I, Div 1, GPS BCD T6
DIP: CL II,III, Div 1, GPS EFG T6
CL I, ZN 1, Ex db ia IIB+H2 T6 Gb
Ex ia tb IIIC T80°C Db
IN
-/OUTPUTS: Urated=30V
