24 SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B
Transmitter
Figure 7: Transmitter with remote mount design
Model
FMT432
FMT452
Design
Integral mount design (see
Figure 4 on page 22), remote mount design; transmitter optionally in single-
compartment housing 2 or dual-compartment housing 1
IP rating
In accordance with EN 60529: IP 65 / IP 67
NEMA rating
In accordance with NEMA 4X
Signal cable length
Maximum 100 m (328 ft), with remote mount design only
Power supply
24 V DC, ±20 %; 100 to 240 V AC (−15 % / +10 %, 47 to 64 Hz)
Outputs in basic version
Current output: 4
to 20 mA active or passive
Digital output 1: passive, configurable as pulse, frequency or switch output
Digital output 2: passive, configurable as pulse, frequency or switch output
Additional optional outputs
The transmitter has two slots in which plug
-in cards can be inserted to provide additional inputs and outputs.
The following plug
-in cards are available:
• Current output (maximum two expansion cards simultaneously)
• Digital output (maximum one expansion card)
• Digital input (maximum two expansion cards)
• 24 V DC power supply for active outputs (maximum one expansion card)
Communication
Standard: HART® 7.1; optional: PROFIBUS DP® / Modbus®
External output zero return
Yes
External totalizer reset
Yes
Counter
Yes
ApplicationSelector
Yes, up to 2 applications
Yes, up to 8 applications
Preconfigured applications
Yes, up to 2 applications
Yes, up to 4 applications
Freely configurable applications
No
Yes, up to 4 applications
Selectable nominal diameters
Yes
Yes
Selectable gas type
No
Yes
Filling function
No
Yes, optional
"VeriMass" diagnosis function
Yes, optional
Yes, optional
Approvals and certificates
Additional approvals
Available on our website
abb.com/flow or on request
