ABB SensyMaster FMT430 - Menu: Display

SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B 111
Menu: Display
Menu / parameter
Description
Display
Language
Selection of
menu language.
Contrast
Contrast setting for the LCD display.
...Operator Pages
Selection of submenu ‘
...Operator Pages’ using .
Up to four user
-specific operator pages (layouts) can be configured for the process display. If multiple operator
pages have
been configured, these can be scrolled through manually on the information level. In the factory setting only Operator Page
1 is enabled.
Autoscroll
If
Autoscroll is enabled, the ‘Autoscroll’ function can also be activated on the information level of the operator menu.
In this function, operator pages are automatically displayed in succession on the process screen, changing every 10
seconds. Manual scrolling through pre
-configured operator pages as described above is no longer necessary. When Auto
scroll mode is enabled, the icon
is displayed in the lower left corner of the screen.
Default setting: Disabled.
Mass Flow Format
Selection of number of decimal places (maximum 12) used to display the corresponding process variables.
Mass Format
Volume Flow@ Format
Volume@ Format
Volume Flow Format
Volume Format
Temperature Format
Density@ Format
Density Format
Date Format
Set the display format for the date and time.
Display Tag
Configuration of the top line in the
display.
Off,
Sensor Location Tag, Bus Address, HART Address, Appl. Description
Display Rotation
The display on the display can be rotated through software by 180°.
Display Test
Start the test of the LCD display with ‘
’. The display test lasts approx. 10 seconds. Various patterns are shown on the
LCD display to check the display.
Display / ...Operator Pages
...Operator Page 1
Selection of submenu ‘...Operator Page 1’ using .
...Operator Page 2
Selection of submenu ‘...Operator Page 2
’ using .
...Operator Page 3
Selection of submenu ‘...Operator Page 3’ using .
...Operator Page 4
Selection of submenu ‘...Operator Page 4
’ using .
