ABB SensyMaster FMT430 - Menu: Diagnostics

122 SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B
… 9 Operation
… Parameter descriptions
Menu: Diagnostics
Menu / parameter
Description
Diagnostics
...Diagnosis Control
Selection of submenu ‘...Diagnosis Control
’ using .
...Diagnosis Values
Selection of submenu ‘...Diagnosis Values’ using .
...Simulation Mode
Selection of submenu ‘...Simulation Mode’ using .
...Output Readings
Selection of submenu ‘...Output Readings’ using .
...SensorCheck
Selection of submenu ‘...SensorCheck
’ using .
...Diag.CurrOut 31/32
Selection of submenu ‘...Diag.CurrOut 31/32’ using .
...Alarm Simulation
Selection of
submenu ‘
...Alarm Simulation
’ using .
Diagnostics / ...Diagnosis Control
Preset Maint. cycle
Sets the service interval.
After the maintenance interval has expired, the corresponding error message ‘
Flowrate to zero’ is set. The setting ‘0’
deactivates the maintenance interval.
Maint. Remain. Time
Time remaining in the maintenance interval until the error message ‘Flowrate to zero’ is set.
Start New Cycle
Resetting of the maintenance interval. The service interval is reset to the value
set in ‘Preset Maint. cycle’.
Diagnostics / ......Diagnosis Values
Temperature gas
Display of the current measuring medium temperature in °C.
Temperature FE elec.
Display of the current temperature of the frontend board electronic unit in °C.
Diagnostics / ......Simulation Mode
Simulation Switch
Manual simulation of measured values. After selecting the value to be simulated, a corresponding parameter is displayed in
the menu ‘
Diagnostics / ......Simulation Mode’. The simulation value can be set here.
The output values correspond to the simulated flowrate entered.
Information ‘
Configuration’ appears in the lower line of the display.
Only one measured value / output can be selected for simulation.
After power
-up / restart of the device, the simulation is switched off.
Off
Curr.Out 31/32/Uco
Curr.Out V1/V2*
Curr.Out V3/V4*
Dig.Out 41/42 State
Dig.Out 41/42 Freq.
Dig.Out 41/42 Pulse
Dig.Out 51/52 State
Dig.Out 51/52 Pulse
Dig.Out V1/V2 State*
Dig.Out V3/V4 State*
Dig.In V1/V2 State*
Dig.In V3/V4 State*
Mass Flow [unit]
Mass Flow [%]
Qv@ Vol.flow [unit]
Qv@ Vol.flow [%]
Temperature [unit]
Temperature [%]
* Only with plug-in card present.
