ABB SensyMaster FMT430 - Menu: Easy Setup

SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B 99
Menu: Easy Setup
Menu / parameter
Description
Easy Setup
Language
Selection of menu language.
Curr.Out 31/32/Uco
Selection of the process value issued via the current output.
The current outputs V1
/ V2 and V3 / V4 are only available if the corresponding plug-in cards are present!
•
Mass Flow [%]: Mass flow in %
•
Volume Flow@ [%]: Standard volume flow in %
•
Temperature [%]: Temperature in %
Curr.Out V1/V2
Curr.Out V3/V4
Dig.Out 41/42 Mode
Selection of the operating mode for the digital output 41
/ 42.
•
Off: Digital output deactivated.
•
Binary: Digital output as a binary output (e.g. as an alarm output).
•
Pulse: Digital output configured as a pulse output. In pulse mode, pulses per unit are output (e.g. 1 pulse per m
3
).
•
Frequency: Digital output configured as a frequency output. In frequency mode, a frequency is issued that is
proportional to the flow rate.
Freq.Out 41/42
Selection of the process value issued via the frequency output.
•
Mass Flow [%]: Mass flow in %
•
Volume Flow@ [%]: Standard volume flow in %
•
Temperature [%]: Temperature in %
Freq.Out 41/42 0%
Set the frequency range for output of the selected process variables.
•
Freq.Out 41/42 100%: Set the frequency for 100 % of the process variable.
•
Freq.Out 41/42 0%: Set the frequency for 0 % of the process variable.
Freq.Out 41/42 100%
Puls.Out 41/42
Selection of the process value issued via the pulse output.
•
Mass Flow [%]: Mass flow in %
• Volume Flow@ [%]: Standard volume flow in %
Puls.Out 41/42 Width
Set the
pulse width for the pulse output.
Bin.Out 41/42
Selection of binary output function.
•
Alarm: The binary output indicates an active alarm. The alarm is selected in the ‘„...Alarm Cfg. 41/42’ menu.
• Batch End: The binary output is activated when the set fill quantity is reached (only if the FillMass function is activated).
Dig.Out 51/52 Mode
Selection of the operating mode for the digital output 51
/ 52.
•
Off: Digital output deactivated.
•
Binary: Digital output configured as a binary output.
•
Frequency: Digital output configured as a frequency output. In frequency mode, a frequency is issued that is
proportional to the flow rate.
•
Pulse 41/42 <)90°: Output of the same pulses as for digital output 41 / 42, phase shifted by 90°.
•
Pulse 41/42 <)180°: Output of the same pulses as for digital output 41 / 42, phase shifted by 180°
Freq.Out 51/52
Selection of the process value issued via the frequency output.
•
Mass Flow [%]: Mass flow in %
•
Volume Flow@ [%]: Standard volume flow in %
• Temperature [%]: Temperature in %
Freq.Out 51/52 0%
Set the frequency range for output of the selected process variables.
•
Freq.Out 41/42 100%: Set the frequency for 100 % of the process variable.
•
Freq.Out 41/42 0%: Set the frequency for 0 % of the process variable.
Freq.Out 51/52 100%
