ABB SensyMaster FMT430 - Menu: Communication

SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B 119
Menu: Communication
Menu / parameter
Description
Communication
...HART
Selection of submenu ‘
...HART’ using .
...Modbus
Selection of submenu ‘...Modbus’ using .
...Profibus
Selection of submenu ‘
...Profibus’ using .
Communication / ...HART
Device Address
Selection of HART® device address.
Note
•
The HART 5® protocol has provisions for creating a bus with up to 15 devices (1 to 15).
If an address greater than 0 is set via HART Command 6, the device operates in multidrop mode. Current loop node
cannot be changed using Command 6 in HART 5. The current output 31 / 32 / Uco is fixed to 3.6 mA. HART
communication takes place through current output 31 / 32 / Uco.
•
The HART 7® protocol has provisions for creating a bus with up to 63 devices (1 to 63).
The address and the current loop mode can be changed via HART Command 6 independently of each other. Here it is not
mandatory to also have the current output fixed to 3.6 mA with an address greater than 0.
If an address greater than 0 is set via the menu, the device will NOT switch automatically to multi-drop mode. The
current loop mode is switched independently.
Curr.Out 31/32/Uco
Selection of the
operating mode for current output 31/32/Uco.
•
Multidrop Fixed: The current output 31/32/Uco supports the HART multi-drop mode, the current output is fixed to
3.6 mA and no longer follows the selected process variable. The process variables can be transferred via the HART
protocol.
•
Normal Signaling: The current output 31/32/Uco transfers the selected process variables. In addition, the process
variables can be transferred via the HART protocol.
•
Power Mode: The current output 31/32/Uco is set permanently to 22.6 mA and no longer follows the selected process
variable. HART communication is deactivated. The current output 31/32/Uco works as a power supply unit for the
operation of the digital output 41 / 42 as an active output.
HART Tag
Entry of
a unique HART® TAG number for device identification.
Alphanumeric, a maximum of 8 characters, upper case only, no special characters.
HART Long Tag
Entry of a unique HART® TAG number for device identification.
Alphanumeric, maximum of 32
characters, ASCII
HART Descriptor
Entry of a HART® descriptor.
Alphanumeric, a maximum of 16 characters, upper case only, no special characters.
HART Message
Display of the alphanumeric measuring point tagging.
HART Manuf. ID
Display of the HART® manufacturer ID. ABB = 26
HART Device ID
Display of the HART® device ID.
HART Find
Select whether the transmitter should respond to the HART® command
73 (Find Device).
•
Off: The transmitter does not respond to command 73.
•
Once: The transmitter responds once to command 73.
• Continuous: The transmitter always responds to command 73.
Last HART Command
Display of the most recently sent HART® command.
