SensyMaster FMT430, FMT450 THERMAL MASS FLOWMETER | OI/FMT430/450-EN REV. B 123
Menu / parameter
Description
Diagnostics /
...Output Readings
Curr.Out 31/32/Uco
Display the current values and statuses of the listed inputs and outputs.
Curr.Out V1/V2*
Curr.Out V3/V4*
Dig.Out 41/42 Freq.
Dig.Out 41/42 State
Dig.Out 51/52 Freq.
Dig.Out 51/52 State
Dig.Out V1/V2
State*
Dig.Out V3/V4 State*
Dig.In V1/V2 State*
Dig.In V3/V4 State*
* Only with plug-in card present.
Diagnostics / ...SensorCheck
...Verify Fingerprint
Selection of submenu ‘...Verify Fingerprint’ using .
...Install Fingerprint
Selection of submenu ‘...Install Fingerprint’ using .
Diagnostics / ...SensorCheck /
...Verify Fingerprint
Verify
Fingerprint testing manual start using
.
The process takes approx. 12 minutes. Make sure that during this time there is no flow
through the sensor (e.g. by shutting
or sealing it off).
Result
Read fingerprint status
Value TDC1
Value TDC2
Value HDC1
Value HDC2
Read VeriMass parameters. See
‘SensorCheck’ diagnosis function on page 134 for additional information on assessing the
results.
•
Value TDC1: Temperature change TDC1
•
Value TDC2: Temperature change TDC2
•
Value HDC1: Heat emission change HDC1
• Value HDC2: Heat emission change HDC2
Diagnostics / ...SensorCheck / ...Install Fingerprint
Determine
Create new commissioning fingerprint using
.
The process takes approx. 12 minutes. Make sure that during this time there is no flow through the sensor (e.g. by shutting
or sealing it off).
Delete (New)
Delete existing commissioning fingerprint using .
