45
Min. control value for basic load (0 to 255) 0 - 255
Function block RTC —
RTC — Control of
additional cooling stage
Control value type
2-point 1 bit, on/off /
2-point 1 byte, 0/100% /
PI continuous, 0-100% /
PI PWM, on/off / fan coil
Cooling type
Area (e.g. cooling ceiling)
5°C 240 min / free
configuration / fan coil 4°C
90 min / free configuration
Setting dependent on
"Control value type"
P-component (x 0.1°C) 10 - 100
I-component (min) 0 - 255
Temperature difference to basic stage (x
0.1°C)
0 - 255
Advanced settings No / yes
Function block RTC —
RTC — Additional
cooling stage
Mode of control value Normal / inverse
Hysteresis (x 0.1°C) 3 - 255
Control value difference for sending of
cooling control value
2% / 5% / 10% / send cyclic
only
Cyclic sending of the control value (min) 1 - 60
Max. control value (0 to 255) 0 - 255
Min. control value for basic load (0 to 255) 0 - 255
Function block RTC —
RTC — Basic load
settings
Min. control value for basic load > 0
Always activate / activate via
object
Basic load active when controller is off No / yes
Function block RTC —
RTC — Combined
heating and cooling
mode
Heating/cooling switchover
Automatic / only for object /
local/via extension unit and
via object
Operating mode after reset Cooling / heating
Heating and cooling control value output
Via 1 object /
via 2 objects
Additional heating and cooling stage control
value output
Via 1 object /
via 2 objects
Function block RTC —
RTC — Setpoint settings
Set value for heating comfort = set value for
cooling comfort
No / yes
Hysteresis for switchover heating/cooling (x
0.1°C)
5 - 100
Setpoint temperature for heating and cooling
comfort (°C)
10 - 40
Set-point temperature for heating comfort
(°C)
10 - 40
Reduction for standby heating (°C) 0 - 15
Reduction for Eco heating (°C) 0 - 15
Setpoint temperature for frost protection (°C) 5 - 15
Setpoint temperature for cooling comfort (°C) 10 - 40
Increase for cooling standby (°C) 0 - 15
Increase for eco cooling (°C) 0 - 15
