50
unsigned
Number of input objects 1 - 8
Output sends
At each input assignment /
when the output object is
changed
Output object
Assumes the largest input
value / assumes the smallest
input value / assumes the
input average
General functions —
channel x —
Light scene actuator
Channel name <Name>
Number of scenes 1 - 8
Number of actuator groups 1 - 8
Duration of telegram delay 00.100 - 10.000 (ss.fff)
Overwrite scenes at download Deactivated / activated
Object type actuator group x
Light scene number / 1 bit
switching / 1 bit blind / 1 byte
0-100% / temperature
Scene number 1 - 64
Scene can be saved Deactivated / activated
Actuator group x Deactivated / activated
Number of light scene 1 - 64
Value Off / on
Value Up / down
Value (%) 0 - 100
Temperature -33.5 - 93.5
Table 4: Overview of applications and functions
