49
Filter function
Deactivated / on filter out /
off filter out
Data flow direction
Input in direction of output /
output in direction of input /
in both directions
Enable object Deactivated / activated
Object value enable object Normal / inverse
Enable object after return of voltage Disabled / enabled
Save input signal Deactivated / activated
General functions —
channel x —
Staircase lighting
Channel name <Name>
Object type/number
One 1-bit object for the input
and output /
two 1-bit objects for the input
and output /
two 1-byte objects for the
input and output
Switch-off delay
00:00:10 - 01:30:00
(hh:mm:ss)
Retriggering Deactivated / activated
Switch-off pre-warning Deactivated / activated
Time for switch-off pre-warning (s) 1 - 5400
Value for switch-off prewarning (%) 1 - 100 (%)
Overwrite light-on and switch-off prewarning
time during download
Deactivated / activated
General functions —
channel x —
Delay
Channel name <Name>
Object type
1 bit switching / 1 bit moving
/ 1 bit stop/adjusting / 1 byte
0-100% / 1 byte 0-255 / 2
byte float / 2 byte signed / 2
byte unsigned / 4 byte float /
4 byte signed / 4 byte
unsigned
Delay time
00:00:01.000-01:00:00.000
(hh:mm:ss.fff)
Retriggering Deactivated / activated
Filter active Deactivated / activated
Filter function
Filter value is delayed,
others are sent direct / filter
value is delayed, others are
suppressed / filter value is
sent direct, others are
delayed / filter value is
suppressed, others are
delayed
Filter value
Setting dependent on object
type
Overwrite delay time during download Deactivated / activated
General functions —
channel x —
Min/max value
transducer
Channel name <Name>
Object type
1 byte 0-100% / 1 byte 0-255
/ 2 byte float / 2 byte signed /
2 byte unsigned / 4 byte float
/ 4 byte signed / 4 byte
