ABB tacteo KNX - Page 48

Description of application and parameters
Overview of functions
Product manual 2CKA001473B9482
│
48
channel x —
Cyclic telegram
Object type
1 bit switching / 1 bit alarm /
1 byte 0-100% / 1 byte 0-255
/ 2 byte float / 2 byte signed /
2 byte unsigned / 4 byte float
/ 4 byte signed / 4 byte
unsigned
Cycle time
00:00:55 - 01:30:00
(hh:mm:ss)
Enable object Deactivated / activated
Object value enable object Normal / inverse
Enable object after return of voltage Disabled / enabled
Cyclic sending
Always activated / activated
at specified value / activated
except specified value
Value for cyclic sending
Setting dependent on object
type
General functions —
channel x —
Priority
Channel name <Name>
General functions —
channel x —
Logic gate
Channel name <Name>
Logical function
AND / OR / XOR / XNOR /
NAND / NOR
Number of input objects 1 - 10
Object type input x 1 bit / 1 byte
Initial value input x
Initialised with 0 /
Initialised with 1
Logic input x Normal / inverse
Object type output 1 bit / 1 byte
Send output object
At each incoming telegram /
at each change of output
object
Value of the output object for logic true
Output is set on 1 / defined
via output default value true
Output default value true True = 0 / true = 1
Output default value true 0 - 255
Value of the output object for logic untrue
Output is set on 0 / defined
via output default value
untrue
Output default value untrue Untrue = 0 / untrue = 1
Output default value untrue 0 - 255
General functions —
channel x —
Gate
Channel name <Name>
Object type
1 bit switching / 1 bit moving
/ 1 bit stop/adjusting / 2 bit
priority / 4 bit relative
dimming 1 byte 0-100% / 1
byte 0-255 / 2 byte float / 2
byte signed / 2 byte
unsigned / 3 byte time / 3
byte date / 4 byte float / 4
byte signed / 4 byte
unsigned / not allocated
