Description of application and parameters
Overview of functions
Product manual 2CKA001473B9482
│
47
(°C)
Function block RTC —
RTC — Fan coil settings -
fan speed levels
Number of fan speed levels 3 levels / 5 levels
Format of the level output
0-5 / 0-255 / 1 bit m off n / 1
bit 1 off n
Level output
At manual operation and
automatic / only at manual
operation
Lowest manually adjustable fan speed level Speed level 0 / speed level 1
Level status evaluation No / yes
Function block RTC —
RTC — Fan coil settings
heating
Fan speed level 1-5 up to control value (0 to
255) heating
0 - 255
Fan speed level limit heating in eco mode No / yes
Max. fan speed level heating in eco mode 0 - 5
Function block RTC —
RTC — Fan coil settings
cooling
Fan speed level 1-5 up to control value (0 to
255) cooling
0 - 255
Fan speed level limit cooling in eco mode No / yes
Max. fan speed level cooling in eco mode: 0 - 5
Function block RTC —
RTC — Summer
compensation
Summer compensation No / yes
(Lower) Starting temperature for summer
compensation (°C)
-127 - 127
Offset of the setpoint temperature for the
entry into summer compensation (x 0.1°C)
-127 - 127
(Upper) exit temperature for summer
compensation (°C)
-127 - 127
Offset of the setpoint temperature for the exit
from summer compensation (x 0.1°C)
-127 - 127
Function block RTC —
LED function
Operating mode
Status illumination / function
illumination
Object type for status object 1 bit / 1 byte 0-100%
Brightness of the colours Dark / bright
Colour for Off Off / yellow - white
Colour for On Off / yellow - white
Colour for Zone 1 (corresponds to 0%) Off / yellow - white
Colour for Zone 2 (starting at 1%) Off / yellow - white
Threshold between Zone 2 and 3 (%) 1 - 98
Colour for Zone 3 Off / yellow - white
Threshold between Zone 3 and 4 (%) 2 - 99
Colour for Zone 4 (up to 99%) Off / yellow - white
Colour for Zone 5 (corresponds to 100%) Off / yellow - white
Colour of function illumination Off / yellow - white
Day/Night mode Deactivated / activated
Light scene memory function Deactivated / activated
Alarm function Deactivated / activated
General functions —
Channel name <Name>
