ActronAir ELY620T - Indoor Unit - Standard Profile

10
Installation and Commissioning Guide 500-700 Tri-Capacity Split Ducted
Doc. No.0525-098 Ver. 2 210330
Installation and Commissioning Guide
Split Tri-Capacity
06.02. Indoor Unit - Standard Profile
TOP PANEL
PLUG
FAN
SAFETY
DRAIN
SAFETY
DRAIN TRAY
ELECTRICAL
BOX
CONDENSATE DRAIN
2 x THERMAL EXPANSION
VALVES (Inside the Unit)
HEAT EXCHANGER
ACCESS PANELS
(BOTH SIDES)
GAS PIPE
LARGE COMPRESSOR
(Crt 2)
LIQUID PIPE
SMALL COMPRESSOR
(Crt 1)
LIQUID PIPE
LARGE COMPRESSOR
(Crt 2)
SCHRADER
VALVES
GAS PIPE
SMALL COMPRESSOR
(Crt 1)
POLYETHYLENE
INSULATION
