Installation and Commissioning Guide 500-700 Tri-Capacity Split Ducted
Doc. No.0525-098 Ver. 2 210330
Installation and Commissioning Guide
Split Tri-Capacity
15.03. BMS Control Wiring Procedures
BMS Card
Vout
J9 FBus 1
J11 BMS2
GND
Tx/Rx
J14pLAN
J10
GND
Tx/Rx
J29FBus2
input 24V +10% -15% 50-60Hz / 28-36V
max power: 28W/20W
NO1
NC1 NC1
J16
J8
Out3
C2
J18
Out4
C2
J19
Out5
C2
J20
NO6
C6
J22
NO7
C7
J23
NO8
C8
J24
C2
V-IN
J21
Out2
C2
J17
J13
J12
J15
1
2
C11
NO11 NO12 NO13
J28
U8 U9 U10 +Vdc +5VR GND
J5
DI7H DI7 DI7C DI8 DI8H
J25
GND Y1 Y2 Y3
J6
U1 U2 U3 GND
J2
D11 D12 D13 D14 GND
J7
U6 U7 +Vdc +5VR GND
J4
46 U5 +Vdc +5VR GND
J3
NO9
C9
NC9
NO10
C10
NC10
J27
Y4 Y5 U11 GND U12 GND D9 D10 DI9C
J26
G G0
J1
OPTIONAL BMS KIT
TO BE PURCHASED SEPARATELY
CONNECT BMS CABLE
INTO BMS KIT
NOTE
ActronAir Control Interface can be left connected or can be dis-connected from the control board.
BMS PART NUMBERS
BMS Connection Type Kit Part Number * Order Form**
MODBUS 485 ICMOD-485 not required
BACNET 485 ICBAC-485 Document 1829
BACNET TCP/IP ICBAC-TCP-IP Document 1828
* To be purchased separately.
** It is necessary to complete and return the Order Form Document for BACNET cards (will be provided by Customer
Care during ordering). The BACNET BMS cards are pre-programmed by ActronAir before being sent out.
DANGER
Hazardous Voltage !
• Always make sure that all power supply, including remote controls, are disconnected before performing maintenance.
Observe proper LOCK-OUT / TAG-OUT (LOTO) procedures to ensure that power cannot be inadvertently energised.
Failure to disconnect power before maintenance procedures can result in serious injury or death.
• Follow all electrical safety precautions when exposed to live electrical components.
• Only qualified technicians are allowed to work on electrical circuits.
• All electrical wiring must be in accordance with the relevant electrical authority rules and regulations.
CAUTION
STATIC SENSITIVE ELECTRONIC DEVICES !
• DO NOT handle electronic devices unless you are wearing an Anti-Static Wrist Strap that is connected to a GOOD EARTH.
Failure to protect the electronic devices from static electricity may cause unrepairable damage.
• Static damaged electronic devices are NOT COVERED for replacement under warranty.
