ActronAir ELY620T - Standard Model with Optional 3-Phase Soft Starters

24
Installation and Commissioning Guide 500-700 Tri-Capacity Split Ducted
Doc. No.0525-098 Ver. 2 210330
Installation and Commissioning Guide
Split Tri-Capacity
12.03. Standard Model with Optional 3-Phase Soft Starters
CAY500TCAY500T
RESIDUAL CURRENT
CIRCUIT BREAKER AND
OVERLOAD
AUXILIARY
TERMINAL
STRIPS
CONDENSER
FAN
CONTACTORS
CM100
CONTROL
CONTROL
ISOLATORS
CONTROLLER
TRANSFORMER
MAIN ELECTRICAL
CONTROL GEARS
MAIN TERMINAL
BLOCK
OPTIONAL
3 PHASE SOFT STARTER
Z  OPTION
CP05
CONTROL
INTERFACE
CONDENSER FAN
SPEED CONTROL
CAPACITORS
230V
GPO
CONTROL
RELAYS
CAY620T and CAY700T CAY620T and CAY700T
RESIDUAL CURRENT
CIRCUIT BREAKER AND
OVERLOAD
AUXILIARY
TERMINAL
STRIPS
CONDENSER
FAN
CONTACTORS
CM100
CONTROL
CONTROL
ISOLATORS
CONTROL
RELAYS
CONTROLLER
TRANSFORMER
MAIN ELECTRICAL
CONTROL GEARS
MAIN TERMINAL
BLOCK
OPTIONAL
3PHASE SOFT STARTER
Z  OPTION
CONDENSER FAN
SPEED CONTROL
CAPACITORS
230V
GPO
CP05
CONTROL
INTERFACE
