19. INTERNAL SENSOR OPERATION
The System is controlled by the ActronAir CM100 control.
(On/Off, Indoor Fan, Compressor, Heat/Cool and Economy)
19.01. Unit ON/OFF Configuration
The unit ON/OFF can be configured to one of the following:
Option 1: MANUAL ON/OFF
Option 2: TIME SCHEDULER
Option 3: EXTERNAL UNIT ON/OFF
Unit status will be shown on the Main Menu. Screen below shows Unit status as Unit On.
Room T.:
19.2
o
C
16.4
o
C
Supply T.:
Comp Rev Vlv
10:20 Unit: Unit On
Unit Status
Option 1: MANUAL ON/OFF
Ensure that Enable DIN 4 to turn the unit On / Off (on screen Ge3) is set to NO.
NO
Bms Cong. Ge3
Enable DIN 4 to turn
the unit On / O : NO
Turn On or Off the unit (on screen A1) when required.
ON
OFF
FAN ONLY
On / O Unit A1
NOTE
Selecting Fan Only will turn on the supply fan without compressor operation.
The Unit ON/OFF is now configured.
Unit ON/OFF CP05
(CP10, CL01 optional)
UNIT STATUS
ON Unit On
OFF OFF by KEY
