ActronAir ELY620T - Indoor Unit - Low Profile

Installation and Commissioning Guide
Split Tri-Capacity
11
Installation and Commissioning Guide 500-700 Tri-Capacity Split Ducted
Doc. No.0525-098 Ver. 2 210330
06.03. Indoor Unit - Low Profile
GAS PIPE
SMALL
COMPRESSOR
(Crt 1)
SAFETY
DRAIN TRAY
SCHRADER
VALVES
POLYETHYLENE
INSULATION
TOP PANEL
HEAT
EXCHANGER
SAFETY
DRAIN
PLUG FANS
ELECTRICAL
BOX
CONDENSATE
DRAIN
ACCESS PANEL
(BOTH SIDES)
2 x THERMAL EXPANSION
VALVES (Inside the Unit)
GAS PIPE
LARGE COMPRESSOR
(Crt 2)
LIQUID PIPE
SMALL COMPRESSOR
(Crt 1)
LIQUID PIPE
LARGE COMPRESSOR
(Crt 2)
