ActronAir ELY620T - With Optional EC Outdoor Fans and 3-Phase Soft Starters

26
Installation and Commissioning Guide 500-700 Tri-Capacity Split Ducted
Doc. No.0525-098 Ver. 2 210330
Installation and Commissioning Guide
Split Tri-Capacity
12.06. With Optional EC Outdoor Fans and 3-Phase Soft Starters
CAY500TCAY500T
RESIDUAL CURRENT
CIRCUIT BREAKER AND
OVERLOAD
AUXILIARY
TERMINAL STRIPS
CONDENSER FAN
CONTACTORS
CM100
CONTROL
CONTROL
ISOLATORS
CONTROL
RELAYS
CONTROL
TRANSFORMER
MAIN ELECTRICAL
CONTROL GEARS
MAIN TERMINAL
BLOCK
OPTIONAL
3 PHASE
SOFT STARTER
Z - OPTION
CP05
CONTROL INTERFACE
230V
GPO
CAY620T and CAY700TCAY620T and CAY700T
RESIDUAL CURRENT
CIRCUIT BREAKER AND
OVERLOAD
AUXILIARY
TERMINAL
STRIPS
CONDENSER FAN
CONTACTORS
CM100
CONTROL
CONTROL
ISOLATORS
CONTROL
RELAYS
CONTROLLER
TRANSFORMER
MAIN ELECTRICAL
CONTROL GEARS
MAIN TERMINAL
BLOCK
OPTIONAL
3 PHASE
SOFT STARTER
Z  OPTION
CP05
CONTROL
INTERFACE
230V
GPO
