18. EXTERNAL INPUT OPERATION
The System is controlled by Third Party Control through wired inputs.
(On/Off, Indoor Fan, Compressor, Heat/Cool and Economy)
REMOTE ON/OFF can only be used when Enable Scheduler is set to NO (on screen D1).
18.01. Unit ON/OFF Configuration.
The unit ON/OFF can be configured as follows:
18.01.01. Wiring ON/OFF Input
Unit ON/OFF can be wired using either Method 1 (REMOTE ON/OFF) or Method 2 ( IN-FAN (24VAC IN)) as
shown below:
Method 1:
Unit ON/OFF is configured by switching REMOTE ON/OFF to COMMON.
COMMON (GND)
11
REMOTE ON/OFF
10
TERMINALS
Method 2:
IN-FAN is operated by switching 24VAC. The unit will turn On or Off when the switch is closed or open
respectively.
IN-FAN (24VAC IN)
6
24VAC OUT
1
TERMINALS
18.01.02. Setting ON/OFF Input
Set Enable DIN 4 to turn the unit On / Off (on screen Ge3) to Yes.
Yes
Bms Cong. Ge3
Enable DIN 4 to turn
the unit On / O󰀨 : Yes
The Unit ON/OFF is now configured.
18.02. EC Indoor Fan Commissioning
Unit control mode is set to EXTERNAL INPUT via Gfc11
G. Service Gf. Service settings Gfc. Thermoregulation Gfc11. S. Configuration
EXTERNAL INPUT
S. Conguration Gfc11
Unit control mode :
EXTERNAL INPUT
Supply Fan Control :
Select Wall Control :
SINGLE CL01
