Installation and Commissioning Guide
Split Tri-Capacity
57
Installation and Commissioning Guide 500-700 Tri-Capacity Split Ducted
Doc. No.0525-098 Ver. 2 210330
Method 2: IN-FAN (24VAC IN)
External Unit ON/OFF is operated by switching 24VAC to IN-FAN terminal.
IN-FAN (24VAC IN)
6
24VAC OUT
1
TERMINALS
19.01.02. Setting ON/OFF Input
Set Enable DIN 4 to turn the unit On / Off (on screen Ge3) to Yes.
Yes
Bms Cong. Ge3
Enable DIN 4 to turn
the unit On / O : Yes
Enable Scheduler (on screen D1) must be No.
Clock D1
No
Day : Tuesday
Date : 17/05/16
Hour : 12:38
Enable Scheduler : No
Ensure ON/OFF Unit (on screen A1) is ON.
ON
OFF
FAN ONLY
On / O Unit A1
The Unit ON/OFF is now configured.
19.02. Indoor Fan Configuration
NOTES
• Commissioning of the EC Fans should be carried out by a qualified technician only.
• Make sure that all instructions are followed accordingly.
• Ensure that connecting duct work and air filters are installed accordingly.
To Next Page
