Installation and Commissioning Guide
Split Tri-Capacity
59
Installation and Commissioning Guide 500-700 Tri-Capacity Split Ducted
Doc. No.0525-098 Ver. 2 210330
19.02.02. Indoor EC Fan Speed setting / Commissioning Procedure Via Control Interface
1. Refer to the Fan Performance Data or the Fan Curve specific to your air conditioner.
2. Determine the Required Fan Speed (%) which matches your Airflow and External Static Pressure
requirements using either the Fan Performance Data or the Fan Curve.
Example:
Unit Model: CAY620T / EVY620T
Airflow: 3200 l/s
External Static Press: 100 Pa
Required Fan Speed: 62.9%
LED FAN STATUS Display (Divide Required Fan Speed by 10): 6.2V ( 62.9 / 10); LED adjustments are in 0.1V increments.
3. Use this Required Fan Speed % to set the medium speed via the control interface, following the menu
navigation:
G. Service Gfc. Service Settings Gfc. Thermoregulation Gfc4. Thermoregulat. (Supply Fan
Settings).
% Medium Fan Speed
Thermoregulat. Gfc4
Supply Fan
Minimum speed: 48.2%
Medium speed: 62.9%
Maximum speed: 90.0%
Supply Fan Temp.
Minimum Temp. 5.0
o
C
Maximum Temp. 50.0
o
C
NOTES
• Minimum and Maximum fan speeds are factory default settings.
• Medium fan speed is the nominal operating fan speed which can be adjusted between the min and max speed.
20. SETTING UP BMS REMOTE DEMAND OPTIONAL
For optional BMS (Remote Demand) Optional Mode, see Installation and Commissioning Guide (0525-036).
21. SETTING ECONOMY CYCLE OPERATION
The Economy mode is based on Dry Bulb ∆T logic only and operates when cooling is required.
The conditions for Economy Cycle are required to be satisfied for a continuous period of 180s to start the Economy
Cycle operation.
The Economy Cycle operation will continue to operate for at least 180s duration.
21.01. Setting Economy Cycle Type
The economy cycle operation can be set via the Control Interface as follow:
G. Service Gf. Service settings Gfc. Thermoregulation Gfc13 S. Configuration
By default Econ. type is set to MODULATE. In this setting, ActronAir internal control logic modulates the damper
positioning.
Type of fans tted
Supply : ACTRON A2FB
Outdoor : 2 SPEED AC
Outdoor Init Speed
OF1: 60.0% OF23: 60.0%
Econ. cycle tted : Yes
Econ. type : MODULATE
S. Conguration Gfc13
