ActronAir ELY620T - Sensor Detail

88
Installation and Commissioning Guide 500-700 Tri-Capacity Split Ducted
Doc. No.0525-098 Ver. 2 210330
Installation and Commissioning Guide
Split Tri-Capacity
32. SENSOR DETAIL
TEMPERATURE SENSORS
Description Location
ActronAir
Part Number
Compressor 1
Discharge Temp. Sensor
Compressor 1
Discharge line
2060-018
Compressor 2
Discharge Temp. Sensor
Compressor 2
Discharge line
2060-018
Outdoor Coil 1
Temperature Sensor
Last return bend of
Coil system 1
2060-006
Outdoor Coil 2
Temperature Sensor
Last Return Bend of
Coil system 2
2060-026
Room Air
Temperature Sensor
Packed together with Installation and
Commissioning Guide
2060-037
Ambient Air
Temperature Sensor
Outdoor Coil System 2
Air Inlet side
2060-036
Indoor Coil
Temperature Sensor
Indoor Coil - Model dependent 2060-016
SWITCHES
Description Location Type
ActronAir
Part Number
Compressor 1
High Pressure Switch
Compressor 1 Discharge Line Pressure Switch 2060-019
Compressor 2
High Pressure Switch
Compressor 2 Discharge Line Pressure Switch 2060-019
Compressor 1
Low Pressure Switch
Compressor 1 Suction Line Pressure Switch 2060-020
Compressor 2 Low
Pressure Switch
Compressor 2 Suction Line Pressure Switch 2060-020
