ACUTRONIC fabian Therapy evolution - Measuring; Ventilation Menu Settings

Technical specifications 89
fabian Therapy evolution | SW 5.1.x
Ref: 121003.EN / Date 2020-01-22
17.3 Measuring
Airway measurement Range: 10 to 110 mbar
Accuracy
2
: ±4%
Resolution: 0.1 to 1 mbar
Inspiratory Oxygen Concentration:
Inspiratory O
2
Concentration Range: 18 to 100 Vol%
Max. Error delivered vs. Set FiO
2
with oxygen monitoring: 3% FiO
2
.
Max. Error delivered vs. Set FiO
2
without oxygen monitoring: 5% FiO
2
.
Response Time to change in FiO
2
: Conventional Ventilation: blender delay is 1 breath.
Total Delay = Blender Delay + Pneumatic Delay
Drift: <1 Vol% per month. <15% rel. over entire service life
Pressure Influence: Proportional to change in Partial Pressure
Warm-Up Time: max. 3 minutes (<30 minutes with New O
2
Sensor)
17.4 Ventilation menu settings
Alarm delay
• 0 to 30 seconds
Automatic O
2
calibration
• 21% Vol.
• 21% Vol. and 100% Vol.
Max. time Manual breath
• 2 to 30 seconds
Flush time
• OFF
• 30 sec
• 60 sec
• 120 sec
NIV Leak compensation
• Off / Low / Middle / High
NIV Tube set
• MediJet
• Infant Flow (Infant Flow or Inspire)
• Infant Flow LP
Ratio of I-time
• Frequency  I–time
• I–time  E-time
Unit for Pressure
• mbar
• cmH2O
2
Measurement uncertainty during performance verification
For pressure measurements: ± 1.75% of reading or 0.1 mbar (whichever is greater)
For volume measurements: ± 1.75% of reading or 0.1 mL (whichever is greater)
For oxygen level measurements: ± 1% absolute
