ADTECH4 SeriesCNC Maintenance Manual
B axis start rate (mm/min)
C axis start rate (mm/min)
004
X axis acceleration (Kpps)
Y axis acceleration (Kpps)
Z axis acceleration (Kpps)
4 axes acceleration (Kpps)
B axis acceleration (Kpps)
C axis acceleration (Kpps)
Range
:
1~9999, 1~9999, 1~8000
Unit
:
mm/min, mm/min, mm/sec
Authority
:
Operation admin
Default
:
3000, 200, 1500
Effective time
:
Instant
Note
:
This parameter is the trapezoid acceleration/deceleration setting used for
GOO instruction
About start speed, 1-2 rotation motor speed is recommended for step
motor; as above, the machine tool moves 5mm when the motor rotates
one cycle, and the speed is 5-10mm/sec (300-600mm/min). For servo
motor, the start and stop shouldn’t have vibration. If this speed is too
high, it will cause vibration during motion, and the step motor will be out
of step.
Parameters affected by the acceleration and start speed include manual
speed, home speed and other non-interpolation motions;
005
X axis positive soft limit (mm)
X axis negative soft limit (mm)
Y axis positive soft limit (mm)
Y axis negative soft limit (mm)
Z axis positive soft limit (mm)
Z axis negative soft limit (mm)
4 axes positive soft limit (mm)
4 axes negative soft limit (mm)
B axis positive soft limit (mm)
