ADTECH4 SeriesCNC Maintenance Manual
Z axis pitch compensation spacing
4 axes pitch compensation spacing
B axis pitch compensation spacing
C axis pitch compensation spacing
Range
:
1 ~ 1000
Unit
:
mm
Authority
:
Super admin
Default
:
10
Effective time
:
Instant
Note
:
Set the compensation spacing from point N to point N + 1 of each axis; if
it is set to 10mm, the spacing from compensation point 0 to 1 is 10mm.
037
X axis pitch compensation start position
Y axis pitch compensation start position
Z axis pitch compensation start position
4 axes pitch compensation start position
B axis pitch compensation start position
C axis pitch compensation start position
Range
:
-9999.999 ~ 9999.999
Unit
:
mm
Authority
:
Super admin
Default
:
0
Effective time
:
Instant
Note
:
Set the starting position of compensation, which corresponds to the
machine coordinate position. Since the number of pitch compensation is
measured from mechanical zero position to a position on the machine, so
that the parameter is set to the mechanical zero position. The parameter is
generally set to 0.
038
X axis pitch compensation end position
Y axis pitch compensation end position
Z axis pitch compensation end position
