ADTECH4 SeriesCNC Maintenance Manual
No.
1
IN0 (X_LMT+)
X axis positive
limit
IN00
2
IN1 (X_LMT-)
X axis negative
limit
IN01
3
IN2 (Y_LMT+)
Y axis positive
limit
IN02
4
IN3(Y_LMT-)
Y axis negative
limit
IN03
5
IN4(Z_LMT+)
Z axis positive
limit
IN04
6
IN5(Z_LMT-)
Z axis negative
limit
IN05
7
IN6 (A_LMT+)
A axis positive
limit
IN06
8
IN7 (A_LMT-)
A axis negative
limit
IN07
9
INCOM1
Input common
terminal (24v+,
12v+)
+24V
10
IN8 (X_STOP0)
X axis zero point
IN08
11
IN9 (Y_STOP0)
Y axis zero point
IN09
12
IN10 (Z_STOP0)
Z axis zero point
IN10
13
IN11 (A_STOP0)
A axis zero point
IN11
14
IN12 (B_STOP0)
B axis zero point
IN12
15
IN13 (C_STOP0)
C axis zero point
IN13
16
IN14
Backup input
IN14
17
IN15
Backup input
IN15
18
INCOM2
Input common
terminal (24v+,
12v+)
+24V
