ADTECH4 SeriesCNC Maintenance Manual
19
IN16
B axis positive
limit
IN16
20
IN17
B axis negative
limit
IN17
21
IN18
C axis positive
limit
IN18
22
IN19
C axis negative
limit
IN19
23
IN20
Backup input
IN20
24
IN21
Backup input
IN21
25
IN22
Backup input
IN22
26
IN23
Backup input
IN23
27
INCOM3
Input common
terminal (24v+,
12v+)
+24V
28
IN24
Backup input
IN24
29
IN25
Backup input
IN25
30
IN26
Backup input
IN26
31
IN27
Backup input
IN27
32
IN28
Backup input
IN28
33
IN29
Backup input
IN29
34
IN30
Backup input
IN30
35
IN31
Backup input
IN31
36
INCOM4
Input common
terminal (24v+,
12v+)
+24V
37
Default expanded input port configuration of 49M series XS14 (milling machine)
Extended digital input interfaces are mainly used for spare extension, which is defined in the following figure
