ADTECH4 SeriesCNC Maintenance Manual
1
ECA+
Encoder phase A input +
2
ECA-
Encoder phase A input -
3
ECB+
Encoder phase B input +
4
ECB-
Encoder phase B input -
5
ECZ+
Encoder phase Z input + (backup )
6
ECZ-
Encoder phase Z input - (backup )
7
NC
Null
8
NC
Null
9
5V-
Negative end of internal 5V power supply; can’t be connected to
external power supply
10
5V-
Negative end of internal 5V power supply; can’t be connected to
external power supply
11
5V+
Positive end of internal 5V power supply; can’t be connected to
external power supply
12
5V+
Positive end of internal 5V power supply; can’t be connected to
external power supply
13
5V-
Negative end of internal 5V power supply; can’t be connected to
external power supply
14
NC
Null
15
NC
Null
Principal axis encoder wiring diagram (49 series XS10):
