10.1.1 AX-CTL Base Card I/O Addresses and Built-in Intelligent Multi-Meter
The following is a list of AX-CTL base card addresses for troubleshooting various input and output circuits:
Item (Address) Description Value (Real-Time) State
01.0 NAC-1 A Volts (Voltage)* (State of Output Voltage)
01.1 NAC-2 A Volts (Voltage) (State of Output Voltage)
01.2 NAC-3 A Volts (Voltage) (State of Output Voltage)
01.3 NAC-4 A Volts (Voltage) (State of Output Voltage)
* ~5.5V quiescent and ~ 27V alarm = Normal
If system has only 2 NACs quiescent and alarm voltages for NAC-3 & NAC-4 = 0V
02.0 NAC-1 A Load (Current)* (State of Output Current)
02.1 NAC-2 A Load (Current) (State of Output Current)
02.2 NAC-3 A Load (Current) (State of Output Current)
02.3 NAC-4 A Load (Current) (State of Output Current)
* Dependent upon quiescent and alarm current draw of notification appliances per circuit
If only 2 NAC circuits per system quiescent and alarm currents for NAC-3 & NAC-4 = 0mA
03.0 Battery (~27V = Normal) (State of Battery Voltage)
04.0 Charger (V) (~27V = Normal) (State of Charger Voltage)
04.1 Charger (I) (Current)* (State of Charger Current)
* Dependent upon whether batteries are being charged, 0mA if no charge needed
04.2 Charger (C) (~25
0
C = Normal) (State of Charger Temp. in
0
C)
05.0 Ground Volts (~13V = Normal)* (State of Ground Voltage)
* Higher voltage = positive ground, lower voltage = negative ground (voltage dependent upon ground potential)
05.1 System Volts (~27V = Normal) (State of System Voltage)
06.0 Aux Supply 1 (Current)* (State of Aux 1 Output Current)
06.1 Aux Supply 2 (Current)* (State of Aux 2 Output Current)
* Dependent upon current draw of auxiliary supply output
07.0 1
st
SLC Load (Current)* (State of 1
st
SLC Loop Current)
07.1 2
nd
SLC Load (Current) (State of 2
nd
SLC Loop Current)
07.2 3
rd
SLC Load (Current) (State of 3
rd
SLC Loop Current)
07.3 4
th
SLC Load (Current) (State of 4
th
SLC Loop Current)
* Dependent upon quiescent and alarm current draw of SLC devices per loop
08.0 1
st
SLC V. Out (~23V = Normal)* (State of 1
st
SLC Loop
Voltage Out
)
08.1 2
nd
SLC V. Out (~23V = Normal)* (State of 2
nd
SLC Loop
Voltage Out
)
08.2 3
rd
SLC V. Out (~23V = Normal)* (State of 3
rd
SLC Loop
Voltage Out
)
08.3 4
th
SLC V. Out (~23V = Normal)* (State of 4
th
SLC Loop
Voltage Out
)
* If system has only 2 SLCs voltage for SLC-3 & SLC- 4 = 0V, and State is RESET
09.0 1
st
SLC V. In (~23V = Normal)* (State of 1
st
SLC Loop Voltage In)
09.1 2
nd
SLC V. In (~23V = Normal)* (State of 2
nd
SLC Loop Voltage In)
09.2 3
rd
SLC V. In (~23V = Normal)* (State of 3
rd
SLC Loop Voltage In)
09.3 4
th
SLC V. In (~23V = Normal)* (State of 4
th
SLC Loop Voltage In)
* 0V if Class B, if Class A and only 2 SLCs voltage for SLC-3 & SLC- 4 = 0V
at 0V State is RESET
10.0 1
st
Switch Input (LCD) L* (State of Control Circuitry)*
10.1 2
nd
Switch Input (LCD) L (State of Control Circuitry)
10.2 3
rd
Switch Input (LCD) L (State of Control Circuitry)
10.3 4
th
Switch Input (LCD) L (State of Control Circuitry)
10.4 5
th
Switch Input (LCD) L (State of Control Circuitry)
10.5 6
th
Switch Input (LCD) L (State of Control Circuitry)
10.6 7
th
Switch Input (LCD) L (State of Control Circuitry)
10.7 8
th
Switch Input (LCD) L (State of Control Circuitry)
* Normal Low (L – open contact), Active High (H – closed contact)
State only changes on circuitry failure
11.0 Relay 1 -* (State of Relay Circuitry)*
11.1 Relay 2 - (State of Relay Circuitry)
11.2 Relay 3 - (State of Relay Circuitry)
11.3 Output 1 - (State of Relay Circuitry)
11.4 Output 2 - (State of Relay Circuitry)
11.5 Output 3 - (State of Relay Circuitry)
11.6 Output 4 - (State of Relay Circuitry)
11.7 Output 5 - (State of Relay Circuitry)
11.8 Output 6 - (State of Relay Circuitry)
11.9 Output 7 - (State of Relay Circuitry)
11.10 Output 8 - (State of Relay Circuitry)
* - = No voltage or current readings, dry contact
State normally equals RESET it only changes on circuitry failure
