4.2.1.3.1.4 OpenAreaSounders
4.2.1.3.1.5 IntelligentManualPullStations
4.2.1.3.1.5.1 SingleandDualActionAX‐APS2
The Intelligent Manual Pull Stations (AX-APS2-xx) consists of a family of
versatile, low profile, high quality addressable manual pull stations. Easily
recognizable during a fire situation, the AX-APS2-xx stations are constructed of
rugged die-cast metal for long life and reliability, with a high gloss red finish and
raised white “FIRE” lettering.
The AX-APS2-xx stations are ANSI/UL 38 Listed and have been found to be in
compliance with the latest requirements of the Americans with Disabilities Act
(ADA). Activation of the pull station meets the requirements for five pound
maximum pull force, and the single hand activation.
Each AX-APS2-xx station is equipped with a jumper selectable status LED,
when the jumper is in the ON position the LED will flash each time the device is
polled. In addition the LED will illuminate steady when the device is in alarm.
Each AX-APS2-xx station also contains a separate Form C relay contact, which
transfers on the stations activation. This Form C relay contact can be utilized for
special application functions (i.e.: controlling a light above the pull station to
indicate activation, closing a door next to the pull station, etc.).
L-
IN
E
L
-
O
u
t
From
Axis
AX
SLC
+
_
To Next
Axis
AX
Peripheral
+
_
Shield Terminal
Mounting Holes
