7.2.2.2 Disabled Condition
If any zones, input devices or output devices have been disabled, the DISABLE LED and if programmed via the PC-
NeT the TROUBLE LED will illuminate. In addition, the NAC DISABLE LED will illuminate if one or more notification
appliance circuits or NAC SLC devices have been disabled. The display will indicate “NEW DISABLED ZONE xxxx”
and the zone and device messages will be displayed. In addition, the lower half of the display will indicate the
quantity of disabled devices (i.e. DISBLs: x”). To view all disabled devices simply scroll through the list utilizing the
navigation down arrow button.
Unacknowledged Zone Disablement with Multiple Devices:
NEW DISABLED ZONE 0001 (Scroll ↓)
FIRST FLOOR
MAIN LOBBY EXIT [PULL STATION]
(Press → for device details)
.WRNs: 0 SUPRVs: 0 DISBLs: 3 TRBLs: 0.
< New unacknowledged Disabled message
< Disabled zone text(32 Characters)
< Disabled device text (26 Characters) /
type of device
< Further device details
< # Warnings, Supervisory, Disables and
Troubles
Unacknowledged Device Disablement:
NEW DISABLED ZONE 0001
FIRST FLOOR
MAIN LOBBY EXIT [PULL STATION]
(Press → for device details)
.WRNs: 0 SUPRVs: 0 DISBLs: 1 TRBLs: 0.
< New unacknowledged Disabled message
< Disabled zone text(32 Characters)
< Disabled device text (26 Characters) /
type of device
< Further device details
< # Warnings, Supervisory, Disables and
Troubles
Acknowledged Disablements:
[Off-Normal State : Total]
DISABLED : 3
(Press
✔ to select)
< Off-Normal line
< Off-Normal type and event total
Only active off-normal events are displayed
< More info pertaining to highlighted event
When the disabled conditions are removed the appropriate indications are cleared. When all disabled conditions are
removed, the DISABLE Indicator is also turned off and the display will revert to Normal System, if no other off
normal condition is present on the system.
To obtain detailed information about the disabled device, press the right arrow () button on the keypad navigation
NEW DISABLED ZONE 0001 (Scroll ↓)
FIRST FLOOR
MAIN LOBBY EXIT [PULL STATION]
NODE 1
JAN 30 2014 11:00 AM SLC 1 Adr 001.0
.WRNs: 0 SUPRVs: 0 DISBLs: 3 TRBLs: 0.
< New unacknowledged Disabled message
< Disabled zone text(32 Characters)
< Disabled device text (26 Characters) /
type of device
< Node # of device location
< Disabled device details
< # Warnings, Supervisory, Disables and
Troubles
