7.8.2.2.2 NAC Outputs
Press the buttons to scroll through and highlight the “NACS” option and then press the ✔ button to disable
them. The display automatically reverts to the Main Disable Menu and the ‘NAC Disabled’ LED will illuminate,
indicating NACs disabled.
ALL OUTPUTS
NACS.
RELAYS
ONLY SELECTED OUTPUTS
Note: On networked systems this only disables NACs connected to this panel.
7.8.2.2.3 Relay Outputs
Press the buttons to scroll through and highlight the “RELAYS” option and then press the ✔ button to disable
them. The display automatically reverts to the Main Disable Menu.
ALL OUTPUTS
NACS
RELAYS.
ONLY SELECTED OUTPUTS
Note: On networked systems this only disables relays connected to this panel.
7.8.2.2.4 Only Selected Outputs
Press the buttons to scroll through and highlight the “ONLY SELECTED OUTPUTS” option and then press the
✔ button to select it.
ALL NACS
NACS
RELAYS
ONLY SELECTED OUTPUTS
The display then shows a list of Zones containing outputs. For example:
[ 2 ZONE(s)with OUTPUTS DISABLED] More>
Zone Mode Location
0008 ENABLED GROUND FLOOR
0100 ENABLED MAIN RECEPTION
Press the buttons to scroll through and highlight the required Zone and then press the button to view the
outputs within this zone. For example:
[ Outputs In Zone 0008] More>
Mode Device Text
Enabled I/O Relay Output
Enabled HVAC RELAY
Enabled NAC MODULE
Enabled RELAY MODULE
Press the button to more information on the outputs, including loop number, address, device type, analog value,
etc.
Press the buttons to scroll through and highlight the required output and then press the
✔ button to change the
device mode from Enabled to Disabled. The device mode will change from Enabled to Disabled and vice-versa.
Press the “Esc” button to return to the Zone list and to the Main Disable Menu.
