1 Introduction / Overview
1.1 Product Description
This manual covers the installation and operation of the AX-CTL-1L, AX-CTL-2 and AX-CTL-4 Intelligent Fire Alarm
Control Panels, also referred to as; Axis
AX
Intelligent Fire Alarm Control Panels or Axis
AX
Panels.
The AX-CTL-1L is a single loop analog addressable intelligent fire alarm control panel with two notification
appliance circuits.
The AX-CTL-2 is a two loop analog addressable intelligent fire alarm control panel with two notification appliance
circuits.
The AX-CTL-4 is a four loop analog addressable intelligent fire alarm control panel with four notification appliance
circuits.
Note: The AX-CTL-1L cannot support optional AX-PSU, AX-LPD or AX-NAC modules.
The AX-CTL-1L, AX-CTL-2 and AX-CTL-4 models are compatibility tested for use with the Advanced range of
intelligent detectors and modules, refer to Section 1.2.2 SLC Devices for a full list of devices. Each SLC (Signaling
Line Circuit) loop supports the connection of 126 devices in any combination of intelligent detectors and modules.
The AX-CTL-1L, AX-CTL-2 and AX-CTL-4 panels have resettable and non-resettable power outputs, each rated 0.5
Amp @ 24 VDC, for connection to four-wire conventional smoke detectors and ancillary devices. Each AX-CTL-1L,
AX-CTL-2 and AX-CTL-4 contains three (3) field programmable Form C relay contacts, each rated 1 Amp @ 30
VDC, defaulted as a fail-safe trouble relay, alarm relay, and supervisory relay. In addition, Axis
AX
fire alarm control
panels support a USB serial port for direct PC connection to allow field configuration programming via Advanced
PC-NeT software.
These Axis
AX
Intelligent Fire Alarm Control Panels are compact, flexible and feature rich, providing ease of
installation and operation and are based on well proven dual, flash based microprocessor technology with on-board
Real Time Clocks.
The operating software features installer friendly “Auto-Learn” and “Loop Detection” facilities for uncomplicated,
trouble-free, commissioning and troubleshooting. The Axis
AX
Intelligent Fire Alarm Control Panels are fully field-
programmable via the on-board alphanumeric graphical display and keypad or from a Windows™ based PC-NeT
field configuration program.
