1.2 System Components
1.2.1 Internal Peripherals
The following internal peripherals can be installed in an Axis
AX
Intelligent Fire Alarm Control Panel:
Document
AX-ACB AC Board 682-033
AX-CTL-1PCB One Loop Base Card PCB 682-034
AX-CTL-2PCB Two Loop Base Card PCB 682-034
AX-LPD SLC/NAC Expansion Module (cannot be used with AX-CTL-1PCB) 682-011
AX-NAC NAC Expansion Module (cannot be used with AX-CTL-1PCB) 682-011
AX-PSU Power Supply Expansion Module (cannot be used with AX-CTL-1PCB) 682-012
AX-DSP Alphanumeric Graphical Display and Keyboard 682-035
D9068P SIA and Contact ID Digital Dialer (requires AX-SEB) 682-200
AX-SEB Serial Expansion Board (for use with D9068P) 682-200
AX-NET4 Network Interface Module, Style 4 (Class B) 682-013
AX-NET7 Network Interface Module, Style 7 (Class A) 682-013
AX-MOXA Fiber Optic Converter Module for AX-NET4 or AX-NET7 682-260
AX-DCI 24 VDC Isolator Module for AX-MOXA 682-260
AX-RL8 Eight Relay Output Module 682-006
AX-RL4 Four Relay Output Module 682-026
AX-MDM 24 VDC Modem Card 682-024
AV-AMP-80 Audio Amplifier with Two 40 Watt Speaker Circuits 682-032
AV-ZS Audio Zone Splitter Module 682-054
AX-PSU-6 6 Amp Power Supply Charger for AV-AMP-80 Amplifier 682-028
AX-012 Panel Strip Printer 682-022
AX-ASW-16 Switch Module with 16 Switches and 48 LEDs 682-020
AX-LED16 LED Annunciator Module, 16 Red and 16 Yellow 682-020
AX-LED32R LED Annunciator Module, 32 Red 682-020
AX-LED32Y LED Annunciator Module, 32 Yellow 682-020
AX-I/O-48 16 Switch Input and 48 LED Driver Outputs 682-020
AX-RL10 10-Way Relay Output Card (used with AX-I/O-48) 682-020
AX-CZM Conventional Zone Module 682-040S/SA
AV-RMIC All Call Remote Microphone (for single hardwired amplifier installation ONLY) 682-046
