Advanced Axis AX-CTL-1L User Manual

www.advancedco.com
53
4.7.2 AX-LPD SLC Circuit Wiring
The AX-LPD module provides two additional SLC loops to the AX-
CTL-2PCB base card.
24V DC, 0.5A
4
SUPERVISED, POWER LIMITED.
Class A, X (Style 7) or B
Minimum return voltage permitted is 17V.
Wire range – 22-12 AWG
Refer to Axis
AX
Wiring Guide Section 9
4
TOTAL OUTPUT LOAD must not exceed panel supply rating – maximum 5A.
O/C OUTPUTS
OUT
+
OUT
-
IN
+
IN
-
LOOP - 1
NC NO COM
RELAY 1
NC NO COM
RELAY 2
NC NO COM
NETWORK
A.C. MAINS!
ANC PSU ANC
FAULT PSU
P-BUS
BAT BAT
-+
START FROM
BATTERY
PROG
RUN
LOCK MEM
MASTER
PROGRAM
RELAY 3
LOOP - 2 NAC - 1 NAC - 2
OUT
+
OUT
-
IN
+
IN
-
A+B+ A-B- A+B+ A-B-
BBAA 0V0V V+V+
AUX-1 AUX-2
0VBV+A
USB
EXT
GND
RX
SERIAL
EXPANSION
RS-232
TX
pp
pp
hh
hh
Figure 29 - AX-LPD or AX-NAC Module Mounting to AX-CTL-2PCB
(Refer to Section 10.1.1)
The following meter readings are
available on the FACP display per SLC:
Output Voltage
Input (Return) Voltage
Load Current
Max/Min Device Current Pulse
